Description

Specifications

Main Features

Voltage Measurement

• DC Voltage: DC 1000 V (Supported)
• AC Voltage: AC 1000 V (Supported)
• Frequency Measurement: Supported
• Voltage TRMS: Supported

Current Measurement

• DC Current: DC 10 A (Supported)
• AC Current: AC 10 A (Supported)
• Current TRMS: Supported

Other DMM Measurements

• Acoustic Continuity: Supported
• Resistance Measurement: Supported
• Capacitance Measurement: Supported
• Conductance Measurement: Supported
• Diode Test: Supported
• Temperature Measurement: Supported
• Logic Frequency Measurement: Supported

Automotive DMM Measurements

• Duty Cycle Function (%): Supported

---

Additional Features

Hand-Held

• Portable Design: Supported

Measurement Detection

• Incorrect Lead Connection Alert: Supported

Low Pass Filter

• Variable Frequency Drive: Supported
• 100 kHz Bandwidth: Supported

Data Hold & Recording

• MAX Hold: Supported
• MAX/MIN/AVG Recording: Supported

Self-Calibration

• Relative Zero Function: Supported

Display

• LCD Display: Supported
• Dual Digital Display: Supported
• Backlight for Visibility: Supported

Power Supply

• Battery Powered: Supported

Buzzer

• Audible Alerts: Supported

Graphical User Interface

• Bar Graph Display: Supported

IP Protection

• IP 40 Protection: Supported

---

Special Accessories

Temperature Probe

• Type K Thermocouple Probe for DMM: Supported

---

Other Applications

Preventative Maintenance

• Voltage Measurements: Supported
• Current Measurements: Supported
• Frequency Measurements: Supported

Troubleshooting

• Field Service Applications: Supported
• Electronics Testing: Supported
• HVAC Diagnostics: Supported

General Purpose Use

• Industrial Testing: Supported

---

Standards Applied

Instrument Safety Towards Users

• EN 55032 – Electromagnetic compatibility of multimedia equipment (Emission requirements)
• IEC 61000-2-12 – EMC – Compatibility levels for low-frequency conducted disturbances
• IEC/EN 61000-3-2 – EMC – Limits for harmonic current emissions
• IEC/EN 61000-3-3 – EMC – Limitation of voltage fluctuations & flicker
• IEC/EN 61000-4-2 – EMC – Electrostatic discharge immunity test
• IEC/EN 61000-4-3 – EMC – Radiated RF electromagnetic field immunity test
• IEC/EN 61000-4-4 – EMC – Electrical fast transient/burst immunity test
• IEC/EN 61000-4-5 – EMC – Surge immunity test
• IEC/EN 61000-4-7 – EMC – Harmonics & interharmonics measurement standards
• IEC/EN 61000-4-8 – EMC – Power frequency magnetic field immunity test
• IEC 61000-6-5:2015 – EMC – Generic standards for power station/substation environments
• Low Voltage Directive (LVD 73/23/EEC) – Electrical safety regulations
• Directive EMC 89/336/EEC – Electromagnetic compatibility compliance

Safety Standards for Electrical Equipment

• IEC/EN 61010 – General safety requirements for electrical measurement equipment
• IEC/EN 61010-1 – Safety for general electrical measurement equipment
• IEC/EN 61010-031 – Safety for handheld probe assemblies
• IEC/EN 61010-2-032 – Safety for handheld current sensors
• IEC/EN 61010-2-033 – Safety for handheld multimeters measuring mains voltage

EMC Safety

• IEC/EN 61326 – EMC requirements for measurement, control, and laboratory equipment
